POWER FOR PROFESSIONALS
ASS39F
FRONTAL VACUUM ASS39F
Front vacuum used for the collection of light materials such as leaves, grass, pine needles, paper and similar for cleaning green spaces.
|
TECHNICAL DATA |
ASS39F |
| Turbine diameter cm | ø 39 |
| Transmission via PTO gearbox rpm | 540 right-hand rotation (1000 left-hand rotation on request) |
| Application | 3-point hydraulic lifting front |
| Suction spout working width cm | 120 |
| Minimum tractor power Hp | 20/40 |
| Weight Kg. | 160 |
As an alternative to the suction spout it is possible to use a mouthpiece with the application of a PVC pipe, diameter 150 or 200 mm maximum lenght 8-10 mt, for the manual collection of material placed in difficult and inaccessible positions with the tractor.
| BASIS VERSION: | |
 |
ASS39F3PK3
Suction spout cm 120 with a brush to hydraulic command, N.1 nose wheel e N.2 back wheels. |
| BY REQUEST: | |
 |
ASS39F3PK3+K1 Suction spout cm 120 with a brush to hydraulic command, N. 1 side cup brush ø cm.55 (right or left) with speed regulator, N.1 nose wheel e N.2 back wheels. |
 |
ASS39F3PK3+K1+K2 Suction spout cm 120 with a brush to hydraulic command, N. 2 side cup brushes ø cm.55 with speed regulator, N.1 nose wheel e N.2 back wheels. |
 |
ASS39F3PK3+K1+K2+K4 Suction spout cm 120 with a brush to hydraulic command, N. 2 side cup brushes ø cm.55 with speed regulator, ANTI-DUST water system for partial dust abatement, N.1 nose wheel e N.2 back wheels. |
ACCESSORIES ON REQUEST:
 |
K8A SUCTION SPOUT BY HAND PIPE MT.5 ø 200 MM |
 |
K18 SUCTION SPOUT BY HAND K8A + TRANSFORMING OF SUCTION SPOUT FOR QUICK COUPLING OF PIPE |
 |
K9 HYDRAULIC OIL COOLING SYSTEM |
